CODE:

HPC575

Download

BOPP Clear 50/Acrylic C-01/WG60

USE:

Minimum labeling temp: 0℃
Service temp: -20℃~80℃ (24h after labeling)
Suitable for daily chemical, personal care, medicine and other fields；such as bottle label, sealing label etc.
Due to the stiffer facestock, this material is not recommended for bottles with diameter less than 20mm or labeling to irregular curved surfaces or very soft bottles.
Not recommended for applications with repeated stick requirements.
Suitable for "no-label look" transparent label.
If need to be applied to wet surface, it must be tested to ensure that it is resistant to being soaked.

Made by Youhua. Sold in the US by Adwins International.

Detail

Application

Fulfill the requirement of RoHS, REACH, VOC

Minimum labeling temp: 0℃

Service temp: -20℃~80℃ (24h after labeling)

Suitable for daily chemical, personal care, medicine and other fields；such as bottle label, sealing label etc.

Due to the stiffer facestock, this material is not recommended for bottles with diameter less than 20mm or labeling to irregular curved surfaces or very soft bottles.

Not recommended for applications with repeated stick requirements.

Suitable for "no-label look" transparent label.

If need to be applied to wet surface, it must be tested to ensure that it is resistant to being soaked.

Printing and processing

With special treatment coated, can be used in multiple printing methods such as letterpress, flexo, gravure, and screen printing etc. UV ink & water-based ink are suitable.
Control the viscosity of print ink, high-contractility bring label crimp, causing the label detach from release paper or warp from label object.
Film special die-cutting knife is recommended, especially the flat die-cutting.
Pay attention to static electricity elimination during production to avoid its impact on product quality.

Storage period and conditions

From date of manufacture: 12 months
Storage conditions: 23±2℃ & relative humidity 50±5%.

Facestock

A kind of transparent bi-axially stretch PP film with a coating, has good performance in water, oil and chemical resistance.

Indicator

Substance

Caliper

Parameter

45±3

50±3

Unit

g/㎡

μm

Method

ISO 536

ISO 534

Adhesive

General purpose membrane emulsion acrylic adhesive
This adhesive complies with FDA section 21(175.105) and can be used for non-contact labeling of food,pharmaceutical and cosmetic Products.

Indicator

Initial Tack

90°Peel Adhesion （20min）

Shear

Parameter

≥8

≥5

≥15

Unit

N/25mm

Method

FTM9,ss

FTM2,ss

FTM8,ss

Liner

Super calendered white glassine

Indicator

Substance

Caliper

Parameter

58±5%

51±5%

Unit

g/㎡

μm

Method

ISO 536

ISO 534

Facestock: A kind of transparent bi-axially stretch PP film with a coating, has good performance in water, oil and chemical resistance.
Indicator	Parameter	Unit	Method
Substance	45±3	g/㎡	ISO 536
Caliper	50±3	μm	ISO 534

Adhesive: General purpose membrane emulsion acrylic adhesive This adhesive complies with FDA section 21(175.105) and can be used for non-contact labeling of food,pharmaceutical and cosmetic Products.
Indicator	Parameter	Unit	Method
Initial Tack	≥8	N	FTM9,ss
90°Peel Adhesion （20min）	≥5	N/25mm	FTM2,ss
Shear	≥15	H	FTM8,ss

Liner: Super calendered white glassine
Indicator	Parameter	Unit	Method
Substance	58±5%	g/㎡	ISO 536
Caliper	51±5%	μm	ISO 534

Statement

All the statements, tech information & recommendations are based on the tests believed to be reliable but do not constitute a guarantee or warranty. All products sold should be tested by the customer in the end-use environment to confirm compliance with the requirements of that environment and to determine which materials to purchase.We reserve the rights of final explanation.
